Sub-compact tractor models
MT122 -with Free Front Loader
MT122- with Belly Mower & Free Front Loader
MT122- with Belly Mower & Free Front Loader
- Engine HP - 21.5
- PTO HP - 15.0
- Transmission - 2 range HST
- 3-Point Lift Capacity - 970 lbs.
- Loader Lift Capacity - 886 lbs.
MT122- with Belly Mower & Free Front Loader
MT122- with Belly Mower & Free Front Loader
MT122- with Belly Mower & Free Front Loader
- Engine HP - 21.5
- PTO HP - 15.0
- Transmission - 2 range HST
- 3-Point Lift Capacity - 970 lbs.
- Loader Lift Capacity - 886 lbs.
- Cutting Width (in.): 60
- Overall Width (in.): 75.6
MT122 with Backhoe & Free Front Loader
MT122 with Mower, Backhoe & Free Front Loader
MT122 with Mower, Backhoe & Free Front Loader
- Digging Depth (in.): 77.8
- Reach from Centerline of Swing Pivot (in.): 144.9
- Loading Height (in.): 59.6
- Swing Arc (deg.): 140
- Transport Height (in.): 74.7
- Bucket Rotating (deg.): 169.4
- Bucket Digging Force (lbs.): 2,097
- Shipping Weight (lbs.): 873
MT122 with Mower, Backhoe & Free Front Loader
MT122 with Mower, Backhoe & Free Front Loader
MT122 with Mower, Backhoe & Free Front Loader
-22HP Sub-compact Tractor
-Front end loader w/50" bucket, Lift Capacity 1,005@Pivot pin(lbs.)
-6' Backhoe w/available 9,12 or 16" bucket
60" Quick-attach Mid mount Mower
MT125 with Free Front Loader
MT125 with 60" Belly Mower & Free Front Loader
MT125 with 60" Belly Mower & Free Front Loader
- Engine HP – 24.7
- PTO HP – 17.2
- Transmission – 2 range HST
- 3-Point Lift Capacity – 970 lbs.
- Loader Lift Capacity – 1005 lbs.
MT125 with 60" Belly Mower & Free Front Loader
MT125 with 60" Belly Mower & Free Front Loader
MT125 with 60" Belly Mower & Free Front Loader
- Cutting Width (in.): 60.0
- Number of Blades: 3
MT125 with Backhoe & Free Front Loader
MT125 with 60" Belly Mower, Backhoe & Free Front Loader
MT125 with 60" Belly Mower, Backhoe & Free Front Loader
- Digging Depth (in.): 75.1
- Reach from Centerline of Swing Pivot (in.): 114.9
- Loading Height (in.): 59.5
- Swing Arc (deg.): 135
- Transport Height (in.): 74.7
- Bucket Rotating (deg.): 169.4
- Stabilizer Spread (Down Position) (in.): 78.5
- Stabilizer Spread (Up Position) (in.): 53.2
- Bucket Digging Force (lbs.): 2,194
- Shipping Weight (lbs.): 661
MT125 with 60" Belly Mower, Backhoe & Free Front Loader
MT125 with 60" Belly Mower, Backhoe & Free Front Loader
MT125 with 60" Belly Mower, Backhoe & Free Front Loader
LS Compact tractors
XJ2025H with Free Front Loader or Add Backhoe
XJ2025H with Free Front Loader or Add Backhoe
XJ2025H with Free Front Loader or Add Backhoe
ENGINE
- Type: 3-cylinder, Indirect-injection, Water-cooled
- Model (Tier 4 ): Mitsubishi S3L2
- Engine HP (Gross): 24.4
- PTO HP: 18.5
- Rated Speed (RPM): 2,500
- Displacement (cu in): 80.4
- Fuel Tank Capacity (gal): 6.6
- Alternator: 12V – 50 Amps
DRIVE TRAIN
- Transmission: Hydrostatic Drive
- No. of Speeds: 2 Ranges
- Brakes: Wet, Multi Disc
- Steering: Hydrostatic Power Steering
PTO
- Type: Independent
- Mid PTO: Standard (2000 rpm)
- Rear PTO: Standard (540 rpm)
HYDRAULIC SYSTEM
- Implement pump (gpm): 5.9
- Steering pump (gpm): 2.6
- Total flow (gpm): 8.5
- Category, 3 pt hitch: CAT 1
- Hitch Lift capacity (lb.): 1,433
- Lift control type: Manual Position
DIMENSION
- Overall length with 3pt (in.): 103
- Wheelbase (in.): 59
- Min. overall width with IND tires (in.): 44.9
- Height to top of ROPS (in.): 92.3
TIRE SIZE
- Industrial Front/Rear: 23 x 8.5 – 12 / 33 x 12 -16.5
- Turf Front/Rear: 23x 8.5 – 12 / 33 x 12.5 – 16.5
WEIGHT
- Total weight without ballast (lbs): 1,609
MT225S w/Free Front Loader
XJ2025H with Free Front Loader or Add Backhoe
XJ2025H with Free Front Loader or Add Backhoe
ENGINE
- Type: 3Cylinder-IDI
- Model (Tier 4): 3TNV80F-ZXKLST(YANMAR)
- Engine HP (Gross): 24.7
- PTO HP: 19.3
- Rated Speed (RPM): 2,800
- Displacement (cu. in.): 77.3
- Fuel Tank Capacity (gal): 6.79
- Alternator (V-A): 12-40
DRIVE TRAIN
- Transmission: HST
- No. of Speeds: 3 Ranges
- Brakes: Wet, Multi Disc
- Steering: Hydrostatic Power Steering
PTO
- Type: Independent
- Rear (rpm): 540
- Mid PTO (option): 2,500
HYDRAULIC SYSTEM
- Control System: Position
- Implement pump (gpm): 5.6
- Steering pump (gpm): 3.7
- Total flow (gpm): 9.3
- Category, 3 pt hitch: CAT 1
- Hitch Lift capacity (lb): 1,896
- Remote Valves: 1 PAIR (Option)
DIMENSION
- Overall length, Frame to link, (in.): 111.9
- Wheelbase (in.): 63.4
- Overall width with tires, in. (in.): 48.7
- Height to top of ROPS (in.): 86.4
TIRE SIZE
- IND (Front/Rear): 23 x 8.5 – 12 / 12 – 16.5
- Turf (Front/Rear): 22 x 8.5 – 12 / 31 x 15.5 – 15
- Versa Turf (Front/Rear): 12 x 16.5/23 x 8.5
WEIGHT
- Total weight without ballast (lbs.): 1,764
MT225S w/ Belly Mower & Free Front Loader
XJ2025H with Free Front Loader or Add Backhoe
MT225S w/ Belly Mower & Free Front Loader
ENGINE
- Type: 3Cylinder-IDI
- Model (Tier 4): 3TNV80F-ZXKLST(YANMAR)
- Engine HP (Gross): 24.7
- PTO HP: 19.3
- Rated Speed (RPM): 2,800
- Displacement (cu. in.): 77.3
- Fuel Tank Capacity (gal): 6.79
- Alternator (V-A): 12-40
DRIVE TRAIN
- Transmission: HST
- No. of Speeds: 3 Ranges
- Brakes: Wet, Multi Disc
- Steering: Hydrostatic Power Steering
PTO
- Type: Independent
- Rear (rpm): 540
- Mid PTO (option): 2,500
HYDRAULIC SYSTEM
- Control System: Position
- Implement pump (gpm): 5.6
- Steering pump (gpm): 3.7
- Total flow (gpm): 9.3
- Category, 3 pt hitch: CAT 1
- Hitch Lift capacity (lb): 1,896
- Remote Valves: 1 PAIR (Option)
DIMENSION
- Overall length, Frame to link, (in.): 111.9
- Wheelbase (in.): 63.4
- Overall width with tires, in. (in.): 48.7
- Height to top of ROPS (in.): 86.4
TIRE SIZE
- IND (Front/Rear): 23 x 8.5 – 12 / 12 – 16.5
- Turf (Front/Rear): 22 x 8.5 – 12 / 31 x 15.5 – 15
- Versa Turf (Front/Rear): 12 x 16.5/23 x 8.5
WEIGHT
- Total weight without ballast (lbs.): 1,764
MT225S w/Backhoe & Free Front Loader
MT225S w/ Backhoe, Belly Mower & Free Front Loader
MT225S w/ Belly Mower & Free Front Loader
ENGINE
- Type: 3Cylinder-IDI
- Model (Tier 4): 3TNV80F-ZXKLST(YANMAR)
- Engine HP (Gross): 24.7
- PTO HP: 19.3
- Rated Speed (RPM): 2,800
- Displacement (cu. in.): 77.3
- Fuel Tank Capacity (gal): 6.79
- Alternator (V-A): 12-40
DRIVE TRAIN
- Transmission: HST
- No. of Speeds: 3 Ranges
- Brakes: Wet, Multi Disc
- Steering: Hydrostatic Power Steering
PTO
- Type: Independent
- Rear (rpm): 540
- Mid PTO (option): 2,500
HYDRAULIC SYSTEM
- Control System: Position
- Implement pump (gpm): 5.6
- Steering pump (gpm): 3.7
- Total flow (gpm): 9.3
- Category, 3 pt hitch: CAT 1
- Hitch Lift capacity (lb): 1,896
- Remote Valves: 1 PAIR (Option)
DIMENSION
- Overall length, Frame to link, (in.): 111.9
- Wheelbase (in.): 63.4
- Overall width with tires, in. (in.): 48.7
- Height to top of ROPS (in.): 86.4
TIRE SIZE
- IND (Front/Rear): 23 x 8.5 – 12 / 12 – 16.5
- Turf (Front/Rear): 22 x 8.5 – 12 / 31 x 15.5 – 15
- Versa Turf (Front/Rear): 12 x 16.5/23 x 8.5
WEIGHT
- Total weight without ballast (lbs.): 1,764
MT225S w/ Backhoe, Belly Mower & Free Front Loader
MT225S w/ Backhoe, Belly Mower & Free Front Loader
MT225S w/ Backhoe, Belly Mower & Free Front Loader
ENGINE
- Type: 3Cylinder-IDI
- Model (Tier 4): 3TNV80F-ZXKLST(YANMAR)
- Engine HP (Gross): 24.7
- PTO HP: 19.3
- Rated Speed (RPM): 2,800
- Displacement (cu. in.): 77.3
- Fuel Tank Capacity (gal): 6.79
- Alternator (V-A): 12-40
DRIVE TRAIN
- Transmission: HST
- No. of Speeds: 3 Ranges
- Brakes: Wet, Multi Disc
- Steering: Hydrostatic Power Steering
PTO
- Type: Independent
- Rear (rpm): 540
- Mid PTO (option): 2,500
HYDRAULIC SYSTEM
- Control System: Position
- Implement pump (gpm): 5.6
- Steering pump (gpm): 3.7
- Total flow (gpm): 9.3
- Category, 3 pt hitch: CAT 1
- Hitch Lift capacity (lb): 1,896
- Remote Valves: 1 PAIR (Option)
DIMENSION
- Overall length, Frame to link, (in.): 111.9
- Wheelbase (in.): 63.4
- Overall width with tires, in. (in.): 48.7
- Height to top of ROPS (in.): 86.4
TIRE SIZE
- IND (Front/Rear): 23 x 8.5 – 12 / 12 – 16.5
- Turf (Front/Rear): 22 x 8.5 – 12 / 31 x 15.5 – 15
- Versa Turf (Front/Rear): 12 x 16.5/23 x 8.5
WEIGHT
- Total weight without ballast (lbs.): 1,764
MT225HE with Free Front Loader
MT225S w/ Backhoe, Belly Mower & Free Front Loader
MT225S w/ Backhoe, Belly Mower & Free Front Loader
- Engine HP – 24.6
- PTO HP – 17.2
- Transmission – HST
- Hitch Lift capacity, lbs(Hitch end) – 1,808 lbs.
- Lift Capacity (LL3300)(@ Pivot pin), lbs. – 1,609 lbs.
MT225HE with Backhoe & Free Front Loader
MT225HE with Backhoe & Free Front Loader
MT225HE with Backhoe & Free Front Loader
- Digging Depth (in): 76.3
- Reach From centerline of swing Pivot (in): 113.1
- Loading Height (in): 63.6
- Swing Arc (deg.): 180
- Transport Height (in): 77.2
- Bucket Rotation (deg.): 180
- Stabilizer Spread (Down Position) (in): 68.7
- Stabilizer Spread (Up Position) (in): 46.4
- Bucket Digging force (lbs): 2,817
MT235HE with Free Front Loader
MT235HE with Backhoe & Free Front Loader
MT235HE with Backhoe & Free Front Loader
- Engine HP – 35
- PTO HP – 28.0
- Transmission - HST 3 Ranges
- 3-Point Lift Capacity - 1,808 lbs.
- Loader Lift Capacity - 1,700 lbs.
MT235HE with Backhoe & Free Front Loader
MT235HE with Backhoe & Free Front Loader
MT235HE with Backhoe & Free Front Loader
- Digging Depth (in): 76.3
- Reach From centerline of swing Pivot (in): 113.1
- Loading Height (in): 63.6
- Swing Arc (deg.): 180
- Transport Height (in): 77.2
- Bucket Rotation (deg.) :180
- Stabilizer Spread (Down Position) (in): 68.7
- Stabilizer Spread (Up Position) (in): 46.4
- Bucket Digging force (lbs.): 2,817
MT240HE with Free Front Loader
MT235HE with Backhoe & Free Front Loader
MT240HE w/ Backhoe & Free Front Loader
- Engine HP – 40
- PTO HP – 32.0 HP
- Transmission - HST 3 Ranges
- 3-Point Lift Capacity - 1,808 lbs.
- Loader Lift Capacity - 2,189 lbs.
MT240HE w/ Backhoe & Free Front Loader
MT345HE with Free Front Loader or add Backhoe
MT240HE w/ Backhoe & Free Front Loader
- Engine HP – 40
- PTO HP – 32.0 HP
- Transmission - HST 3 Ranges
- 3-Point Lift Capacity - 1,808 lbs.
- Loader Lift Capacity - 2,189 lbs.
MT345HE with Free Front Loader or add Backhoe
MT345HE with Free Front Loader or add Backhoe
MT345HE with Free Front Loader or add Backhoe
The MT3E Series provides a variety of horsepower ratings and transmissions to accommodate any customers needs. Those customers requiring value and power will find plenty of both in this robust series of LS tractor.
LOADER LIFT CAPACITY 2,229 lbs. HITCH LIFT 2,910 lbs. lightning ENGINE HP 45.0 HP tractor wheel PTO HP 36.0 – 38.2 HP
MT355E with Free Front Loader or add Backhoe
MT345HE with Free Front Loader or add Backhoe
MT345HE with Free Front Loader or add Backhoe
The MT3E Series provides a variety of horsepower ratings and transmissions to accommodate any customers needs. Those customers requiring value and power will find plenty of both in this robust series of LS tractor.
LOADER LIFT CAPACITY 2,229 lbs. HITCH LIFT 2,910 lbs. lightning ENGINE HP 55.0 HP tractor wheel PTO HP 44.0 – 46.7 HP
CAB Tractors
MT335HC w/Loader Heat/AC/Radio or Add Backhoe
MT335HC w/Loader Heat/AC/Radio or Add Backhoe
MT335HC w/Loader Heat/AC/Radio or Add Backhoe
- Engine HP - 35
- PTO HP – 28
- Transmission - 3-Range Hydrostatic Drive (HST)
- 3-Point Lift Capacity - 1,808 lbs.
- Loader Lift Capacity - 2,178 lbs.
MT342HC w/Loader Heat/AC/Radio or Add Backhoe
MT335HC w/Loader Heat/AC/Radio or Add Backhoe
MT335HC w/Loader Heat/AC/Radio or Add Backhoe
- Engine HP – 42
- PTO HP – 35.7 Hydr or 33.6 Gear
- Transmission – Synchro shuttle or HST
- Hitch lift capacity, lbs (Hitch end) – 2,755
- Lift Capacity (@Pivot pin), lbs (LL4106) – 2,680
MT347HC w/Loader Heat/AC/Radio or Add Backhoe
MT335HC w/Loader Heat/AC/Radio or Add Backhoe
MT347HC w/Loader Heat/AC/Radio or Add Backhoe
- Engine HP - 47
- PTO HP – 36.0
- Transmission - 3 Range HST (Hydrostatic Drive Transmission)
- 3-Point Lift Capacity - 2,755 lbs.
- Loader Lift Capacity - 2,713 lbs.
MT352HC w/Loader Heat/AC/Radio or Add Backhoe
MT357HC w/Loader Heat/AC/Radio or Add Backhoe
MT347HC w/Loader Heat/AC/Radio or Add Backhoe
- LOADER LIFT CAPACITY 2,680 lbs.
- HITCH LIFT 2,755 lbs.
- ENGINE HP 52.0 HP
- PTO HP 41.6 – 44.2 HP
MT357HC w/Loader Heat/AC/Radio or Add Backhoe
MT357HC w/Loader Heat/AC/Radio or Add Backhoe
MT357HC w/Loader Heat/AC/Radio or Add Backhoe
ENGINE
- Type: 3Cylinder, liquid-cooled, Diesel, TC, CRDI
- Model (Tier 4):L3C19-T
- Engine HP (Gross): 57
- PTO HP: 48.4 Hydr / 45.6 Gear
- Rated Speed (RPM): 2,600
- Displacement (cu. in.): 114.7
- Fuel Tank Capacity (gal): 12.4 (CABIN) / 10.6 (ROPS)
- Alternator V-A: 12 – 70
DRIVE TRAIN
- Transmission: Synchro shuttle / HST
- No. of Speeds: F16 x R16(GEAR) / 3 Ranges(HST)
- Brakes: Wet, Multi-disc
PTO
- Type: Independent
- Rear, rpm: 540
HYDRAULIC SYSTEM
- Control System: Position/Draft
- Implement pump (gpm): 8.2
- Steering pump (gpm): 4.1 Gear / 5.5 Hydro / 6.8 Hydro Cab
- Total flow (gpm): 12.3 Gear /13.7 Hydro / 15.0 Hydro Cab
- Category, 3 pt hitch: CAT 2
- Hitch Lift capacity (lb): 2,755
- Remote Valves: 2 PAIR (1 DETENT, 1 STD)
DIMENSION
- Overall length, Bumper to link (in.): 133
- Wheelbase (in.): 73.2
- Overall width with tires (in.): 62.5
- Height to top of rops (in.): 95 ROPS / 90 Cab
TIRE SIZE
- Ag (Front / Rear): 9.5 – 16 / 13.6 – 24
- IND (Front / Rear): 12 – 16.5 / 17.5L – 24
- Turf Tire (Front / Rear) 28 x 8.5 – 15 / 41 x 14 – 20
WEIGHT
- Total weight without ballast (lbs.): 3,869 – 4,446(cab)
